This bike was used for a season, and is currently in use now by the owners; parts spec may change.

---

Frame

• Material: FORM™ Alloy
• Features: Press Fit BB, Integrated Display, Internal Cable Routing
• Specifications: 197mm Rear Spacing, Tapered Zerostack Headtube, Dropper Post Compatible

---

Fork

• Model: Rocky Mountain Carbon Fat

---

Headset

• Brand: FSA Orbit NO.57E ZS44|56
• Bearings: Sealed 36°x45° Bearings
• Dimensions:
  • Upper: 30.2mm x 41mm x 7.1mm
  • Lower: 40mm x 51.8mm x 7.5mm
  • Crown Race: 1.5"

---

Stem

• Model: Rocky Mountain 35 AM
• Features: 5° Rise, All Sizes = 40mm

---

Handlebar

• Model: Rocky Mountain AM
• Specifications: 780mm Width, 25mm Rise, 9° Backsweep, 5° Upsweep, 35 Clamp

---

Grips

• Type: Rocky Mountain Lock On Foam

---

Brakes

• Model: Sram G2 R 4 Piston
• Pads: Resin Pads

---

Drivetrain

• Shifters: Sram NX-1E Eagle
• Rear Derailleur: Sram GX Eagle
• Cranks & Chainring:
  • Race Face Ride Cinch 34T
  • 24mm Spindle
  • Crank Length: SM-MD = 170mm | LG-XL = 175mm
• Bottom Bracket: Race Face BB124 24mm
• Cassette: Sram XG-1275 10-52T
• Chain: Sram NX Eagle (E-MTB Approved)

---

Wheels

• Front Hub: Rocky Mountain Sealed 150 x 15mm
• Rear Hub: DT Swiss 350 197mm | 36T Star-Ratchet
• Spokes: DT Swiss Champion 2.0
• Rims: WTB KOM Light i76
  • TCS Tubeless
  • 32H
  • Tubeless Ready (Tape/Valves Included)
• Tires:
  • Front: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Included, Not Installed)
  • Rear: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Included, Not Installed)

---

Seatpost

• Model: X Fusion Manic Composite 30.9mm
• Specifications:
  • XS = 100mm
  • SM = 100mm
  • MD = 125mm
  • LG-XL = 150mm

---

Saddle

• Model: WTB Volt Race 142

---

Drive System

• Model: Dyname 4.0 Mountain Bike Drive
• Specifications:
  • 700W Max Power | 250W Nominal Power | 108Nm Torque
  • Low RPM - High Efficiency Class 1 eMTB System
  • Designed in Canada
• Features: Rocky Mountain Micro Remote

---

Battery

• Type: 720 Wh Removable Integrated Li-Ion
• Charging Time:
  • 100% Charged: 3:55 (4A) / 7:35 (2A)
  • 80% Charged: 2:55 (4A) / 6:05 (2A)

---

Display

• Model: Rocky Mountain Jumbotron
• Features:
  • Drive System Customization
  • Battery & Assist Level Monitoring
  • Trip, Speed, Cadence
  • Top Tube Integration

---

Remote

• Model: Rocky Mountain Micro Remote

---

Charger

• Model: Rocky Mountain Powerplay FAST Charger V1
• Specifications: 4A | 48V | Higo Deep Socket Connector
• Compatibility: Overtimepack Compatible (Dyname 4)

---
