Its total enduro capabilities can help you secure that “top step” and tackle demanding group rides with confidence. The Altitude Alloy features internal routing, size-specific tune, and the refined RIDE-4™ adjustment system. With so much capability in your corner, it’s time to push limits, climb faster, and charge.

---

Key Features

Frame

• FORM™ Alloy
• Full Sealed Cartridge Bearings
• Threaded BB
• Internal Cable Routing
• 2-Bolt ISCG05 Tabs
• RIDE-4™ Adjustable Geometry
• 160mm Travel
• FORM™ Alloy Rear Triangle

Fork

• Fox 38 Float EVOL GRIP Performance Series
• 170mm Travel
• 27.5 = 37mm Offset | 29 = 44mm Offset

Front Travel

• 170mm

Shock

• Fox Float X Performance
• Sealed Bearing Eyelet
• 40x10mm F Hardware
• SM = 210x55mm | MD - LG - XL = 230x60mm
• Size-Specific tune in FAQ

Rear Travel

• 160mm

---

Components

Headset

• FSA ZS56/66 Reach Adjust
• 0mm Cups Installed | +/- 5mm Cups Included
• Sealed Stainless 36°x45° Bearings
• 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower
• 1.5" Crown Race

Stem

• Rocky Mountain 35 AM
• 0° Rise
• All Sizes = 40mm

Handlebar

• Rocky Mountain AM
• 780mm Width
• 38mm Rise
• 9° Backsweep | 5° Upsweep
• 35 Clamp

Grips

• ODI Elite Pro Lock On

Brakes

• Shimano SLX Trail 4 Piston
• Metal Pads

Shifters

• Shimano SLX

Rear Derailleur

• Shimano XT

---

Drivetrain

Cranks & Chainring

• Race Face Aeffect Cinch
• 32T | 24mm Spindle
• SM = 165mm | MD - XL = 170mm

Bottom Bracket

• Shimano Threaded BBMT501-B

Cassette

• Shimano Deore 10-51T 12spd

Chain

• Shimano M6100

---

Wheels and Tires

Front Hub

• Novatec D791SB Sealed Boost 15mm

Rear Hub

• Shimano XT Boost 148mm

Spokes

• DT Swiss Competition 2.0/1.8/2.0

Rims

• WTB ST i30 TOUGH TCS 2.0
• 32H
• Tubeless Set Up | Sealant Incl

Tires

• Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready
• Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
• Tubeless Set Up | Sealant Incl

---

Seat and Saddle

Seatpost

• X Fusion Manic Composite 30.9mm
• SM = 150mm | MD = 170mm | LG - XL = 200mm

Saddle

• WTB Solano Fusion Form 142
• Cromoly Rails

---

With its high-performance components and cutting-edge design, the Altitude Alloy is ready to dominate steep trails and weekend rides alike.
